Product Overview
The 2711P-T12W22D9P Allen Bradley Panel View Standard is a high-resolution, color touchscreen operator interface designed for industrial automation applications. It offers intuitive operation and reliable performance, making it ideal for monitoring and controlling industrial processes.
Key Features:
12.1" Color Touchscreen: Provides clear and intuitive operation for enhanced user experience.
High Resolution: Ensures detailed and precise display of process data and graphics.
Durable Construction: Built to withstand harsh industrial environments.
Versatile Connectivity: Supports multiple communication protocols for easy integration with various automation systems.
User-Friendly Interface: Simplifies operation and reduces training time for operators.
Comprehensive Protection: Features a rugged design with a protective glass cover for durability.
Technical specifications :
| Brand | Allen-Bradley |
| Display Type | Color active-matrix TFT |
| Display Size | 12.1 in. ; wide screen |
| Part Number/Catalog No. | 2711P-T12W22D9P |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Family: | PanelView Plus 7 Performance terminals |
| Operator Input: | Touch |
| Display Area: | 261 x 163 mm (10.3 x 6.4 in.) |
| Resolution: | 1280 x 800 WXGA, 18-bit color graphics |
| Touch: | Analog resistive Actuation: 1 million presses; operating force: 100 g |
| System Memory: | 512 RAM, 512 MB nonvolatile memory (approx. 80 MB free user memory) |
| Communication ports: | Two (2) Ethernet, Three (3) USB host |
| Input Voltage range: | 18-30 VDC |
| Power Consumption: | 50 W max (2.1 A at 24V DC) |
| Backlight: | White light-emitting diode, solid state Life: 50,000 h min at 40 °C (104 °F) to half-brightness, backlight is not replaceable |
| Product Line | Panelview Plus 7 |
| Product Type | Human-Module Interface |
| Input Type | Touchscreen |
| Memory | 512 Mb |
| Input Voltage | 24 Volts DC |
| Backlight | LED |
| Weight | 5.6 pounds |
| Dimensions | 24.6 x 13.39 x 6.9 centimeters |
Application Industry:
1. Power industry, the elevator industry, parking lot, automobile, automobile supporting.
2. Feed industry, aluminum smelting machinery, refrigeration industry.
3. Iron and steel industry, combustion control system, non-ferrous metal smelting.
4. Glass industry, engineering machinery, textile machinery, water treatment.
